GARDNER DENVER PZ-10,PZ-11
|
Item |
Part No. |
Description |
Qty per Pump |
|
1 |
BL-202PZL029B |
Fluid Module, Studded (Included Items 2 – 9) |
(3) |
|
2 |
|
Fluid Module, Only |
3 |
|
3 |
BL-201PZL110 |
Stud – Frame, Liner Clamp |
24 |
|
4 |
BL-205PZL110 |
Stud – Frame |
24 |
|
5 |
BL-50B36 |
Nut – Frame, Liner Clamp |
60 |
|
6 |
BL-204PZL110 |
Stud – Threaded Ring |
72 |
|
7 |
BL-50B34 |
Nut – Threaded Ring, Discharge Manifold |
84 |
|
8 |
BL-202PZL110 |
Stud – Discharge Manifold |
12 |
|
9 |
BL-200PZL587 |
Cap – Valve Lock |
6 |
|
10 |
BL-200PZL147 |
Cover – Valve |
6 |
|
11 |
BL-2007674 |
Valve Guide Bushing – Discharge |
3 |
|
12 |
BL-204PZL715 |
Gasket – Valve Cover |
6 |
|
13 |
BL-200PZL387 |
Threaded Ring |
6 |
|
|
BL-200PZL |
Valve Guide Assembly (Included Items 14 – 18) |
(3) |
|
14 |
BL-2011701 |
Retainer Plate |
3 |
|
15 |
BL-200PZL483 |
Valve Guide – Suction |
3 |
|
16 |
BL-2007674 |
Valve Guide Bushing – Suction |
3 |
|
17 |
BL-95W2 |
Lock Washer – Valve Guide / Suction |
6 |
|
18 |
BL-655EE06S |
Bolt – Valve Guide / Suction |
6 |
|
19 |
BL-25AL35 |
Gasket – Discharge Manifold |
3 |
|
20 |
BL-25BE41 |
Gasket – Suction Manifold |
3 |
|
21 |
BL-200PZL455 |
Liner Clamp |
3 |
